All tower equipments taking PP as main material are padding spray tower. Padding materials is PP material Pall ring or hollow sphere. It has excellent absorption and purification effect.

Structural features:

PP absorption tower has 2 kinds of structure: vertical and horizontal type.

Advantages:

High purification efficiency, excellent corrosion resistance, light weight, convenient for installation and maintenance, high specific strength, beautiful appearance, small space cover and large treatment capacity of exhaust gas

Scope of application:

For absorption, washing and purification treatment of exhaust gas in chemical, petrochemical, medical, food, oil and grease, dyeing and printing, metallurgy, environmental protection and compound fertilizer industries

Technical speciality:

1.pressure loss: <390-780Pa

2. applicable temperature: PP material -10℃-120℃

3. specification and treatment capacity of vertical tower: Φ300-Φ3000mm, 1200m3/h-30000m3/h

4. Specification of horizontal tower is designed on customer requirement

PTL-I type                                                                                                                            Unit: mm

Model	Handling capacity of air M3/h	Ф1	Ф2	Ф3	H	H1	H2	H3	Purifying rate %	Recommend pump
PTL-I-500	1200	800	500	960	1200	2400	400	4000	90	25FP-8
PTL-I-600	2000	1000	600	1160	1200	2400	400	4000	90	25FP-8
PTL-I-700	3000	1000	700	1160	1300	2700	500	4500	90	32FP-11
PTL-I-800	4000	1200	800	1360	1300	2700	500	4500	90	32FP-11
PTL-I-1000	5000	1400	1000	1600	1400	3600	500	5500	90	40FP-18
PTL-I-1200	6000	1600	1200	1800	1400	3600	500	5500	90	40FP-18
PTL-I-1400	8000	1800	1400	2000	1400	4000	600	6000	90	50FP-22
PTL-I-1600	10000	2000	1600	2200	1400	4000	600	6000	90	50FP-22
PTL-I-1800	15000	2200	1800	2400	1500	4300	700	6500	90	50FP-22
PTL-I-2000	20000	2400	2000	2600	1500	4300	700	6500	90	65FP-26
PTL-I-2200	25000	2600	2200	2800	1500	4800	700	7000	90	65FP-26
PTL-I-2500	30000	2800	2500	3000	1500	4800	700	7000	90	65FP-26
